Factory Lead Time

10 Weeks

Mounting Type

PCB, Through Hole

Package / Case

4-SIP Module

Voltage - Input (Nom)

5V

Power - Output (Max)

250mW

Power Dissipation (Max)

250mW

Operating Temperature

-40°C~85°C

Packaging

Tube

Series

IK (0.25W)

Published

2010

Size / Dimension

0.46Lx0.24W x 0.50 H 11.7mmx6.0mmx12.7mm

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

4

ECCN Code

EAR99

Type

Isolated Module

Applications

ITE (Commercial)

Power Rating

250mW

Terminal Position

SINGLE

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

1

Terminal Pitch

2.54mm

Depth

11.68mm

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

JESD-30 Code

R-XSMA-T4

Number of Outputs

1

Qualification Status

Not Qualified

Efficiency

66%

Voltage - Isolation

1kV

Voltage - Input (Max)

5.5V

Operating Supply Voltage

5V

Trim/Adjustable Output

NO

Current - Output (Max)

50mA

Current - Output

50mA

Output Power

250mW

Voltage - Output

5V

Current - Output 1

50mA

Nominal Input Voltage

5V

Nominal Output Voltage

5V

Max Input Voltage (DC)

5.5V

Min Input Voltage (DC)

4.5V

Height

12.7mm

Width

6mm

REACH SVHC

Unknown

RoHS Status

ROHS3 Compliant
